ZIM 1842 Concrete Block and Paverstone Making Machine: Is special design machine for block and paverstone production that works fully automatic.The movement of the machine is programmed the PLC microprocessor computer.

By changing moulds all kinds of blocks, paverstones, curbstones, grasstones, lentos and precast concrete elements can be produced in a serial way.
20cm block can be produced 18 units, and interlock can be produced 42 units in one press. Machine is able to produce the insulated block upon demand.

Our company’s special production oil bathed vibrator is used. It has 6 engines with total power of 33 kW. Thus, it can produce smoothly and quickly.

We use pneumatic bellows in machine mould connections, due to this system vibration on mould is expanded regular and uniform.

Mortar part of the machine is moving on strong chromium columns. Height regulations also done automaticly but not with manpower.

There is ZIM18 model which is designed with single bunker for customers who want to produce materials as block, hollow block and single layer paverstones.


Pallet Dimensions Pallet with leg: 1400mmx1450mmx50mm
Rack System: 1400mm x 1450mm x 50mm
Mould Usage Area 1300mm x 1350mm
Minimum Product Height 50 mm
Maximum Product Height 300 mm
Pressing Time 17 – 25 seconds
Capacity of Machine Mortar Bunker 2 x 2500 dm³
Working Pressure 80 – 150 bar
Electric System Schneider - Siemens
Totaş Weight* 29.500kg
